Custom measurements for a custom fit

We care about how your replacement awnings & slide toppers fit.

Stone Vos asks for your replacement awning & slide topper measurements to give you the best possible outcome. You can find printable measuring guides at the bottom of this page for your convenience.

How to measure awnings, Carefree, Paramount, RV patio awnings, RV canopy, replacement awnings

We take care to ensure that you get the right measurements.

 Please call us at 352-942-0224 or email us at info@stonevos.com or cheryl@stonevos.com for printable measuring guides.



Carefree of Colorado

How to measure your assemblies for awnings & slide toppers.

Carefree, Carefree of Colorado, SOK II, SOK II, SOC, slide topper, RV slideout topper, side out topp

SOC, Alpine, SOK II, SOK III and Ascent Slide Topper Assemblies

1. For all Carefree of Colorado slide topper assemblies measure      the roller tube in between the endcaps.  You are measuring the length of the aluminum roller tube without any obstructions such as collars or gears.

2. Measure the slide depth extension from coach wall to the outside of the slide wall.

3. Ascent models: some have a "Weatherslat" at the coach wall attached .  Measure the length of the metal slat and then the depth of the soft connect (usually anywhere from 1 to 2.25 inches).

Carefree, Carefree of Colorado, Omega, Omega II, Omega I, replacement awnings, slide topper

Omega I Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric and then the length of the roller tube in between the collar or gears.

2.  Measure the length, left to right, of the slide flange.

3. Option 1: No metal cover: Measure the depth of the awning fully deployed from coach rail bead to rollertube bead.

Option 2: Metal cover: Measure the depth from the metal cover to the rail on the rollertube.

4.  Measure the depth of the slideout from coach wall to slide wall.

5.  Find valance depth.


How to measure an Omega II, replacement slide topper window awning, replacement awnings

Omega II Awnings (in inches):

1.  Measure the length, left to right, of the current awning/slide topper fabric.

2.  Measure the length, left to right, of the slide flange.

3.  Measure the depth or extension  of the topper/window awning fully deployed from bead to bead.

4.  Measure the depth of the slide out from coach wall to slide wall.

Carefree, Carefree of Colorado, replacement window awning, scallops, SL replacement awning, CoachGua

Manual Window & Door Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric and then the length of the rollertube in between the endcaps.  Measure the length of the metal cover if you have one.

2.  Measure the depth or extension  of the awning fully deployed from bead to bead.

3.   Measure the depth of the decorative valance flap.

4.  State whether your valance is scalloped or straight.

Replacement door awning, CoachGuard acrylic,Solarfix Teflon thread, double-stitched,10 year warranty

Electric Door Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension  from lead rail back to the rollertube at the coach wall.

4.  Estimate how much of the awning is wrapped on the tube.

Replacement awning, CoachGuard acrylic,Solarfix Teflon thread, double-stitched,10 year warranty

Vertical Arm Patio Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric and then the length of the rollertube in between the endcaps.

2.  Measure the length, left to right, of the metal cover if you have one.

3.  Measure the depth or extension  of the patio awning fully deployed from bead to 1st bead on.

4.  Find out if your awning wraps around 1/3 of the roller tube or not.

5.  Measure the depth of the valance flap.

6. For Eclipse models, measure the depth of the soft connect if you have one.

Replacement patio awning, CoachGuard acrylic,Solarfix thread, double-stitched,10 year warranty

Lateral Arm Patio Awnings (in inches):

 1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension  of the patio awning from the lead rail back to the roller tube.

3.  Estimate how much of a wrap is on the roller tube.

Replacement door awning, CoachGuard acrylic,Solarfix Teflon thread, double-stitched,10 year warranty

Lateral Arm Dual Pitch Patio Awnings (in inches):

 1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension  of the patio awning from the lead rail back to the roller tube.

3.  Estimate how much of a wrap is on the roller tube.

Replacement door awning, CoachGuard acrylic,Solarfix Teflon thread, double-stitched,10 year warranty

Lateral Arm Latitude Patio Awnings (in inches):

 1.  Measure the length, left to right, of the current awning fabric at the coach rail then measure the length, left to right, of the awning at the roller tube.  These awnings are tapered so the lengths will be different.

2.  Measure the depth or extension of the patio awning from bead to 1st bead on the roller tube.

3.  Measure the depth or drop on the valance flap.

* Due to the thickness of our materials we cannot install a light wire in this model as it will not roll up properly.


A&E Dometic

How to measure your assemblies.

A&E, Dometic, Slide topper,slideout topper, replacement awning, Migliore, 10 year warranty

A&E, A&E Elite, Dometic Deluxe, Dometic Full Cover Slide Topper Assemblies

 1. Measure the roller tube in between the endcaps or collars.  You are measuring the length of the aluminum roller tube without any obstructions such as collars or gears.  Measure the length of the current slide topper also.                                                                         2. Measure the slide depth extension from coach wall to the outside of the slide wall.

Window awning, Double stitched,Solarfix thread, replacement awning, CoachGuard, 10 year warranty

A&E Dometic Manual Window & Door Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric and measure the length of the metal cover if you have one.

2.  Measure the depth or extension  of the awning fully deployed from bead to bead.

3.  Measure the depth of the decorative valance flap.

4.  State whether your valance is scalloped or straight.

Window awning, Double stitched,Solarfix thread, replacement awning, CoachGuard, 10 year warranty

A&E Oasis & Oasis Elite Electric Door Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension  from lead rail back to the rollertube at the coach wall.

3.  Estimate how much of the awning is wrapped on the tube.

Patio awning, Double stitched Solarfix thread, replacement awning, CoachGuard, 10 year warranty

A&E Dometic WeatherPro Awnings with 5 or 6 Slat metal cover

1.  Go to the bottom of this page and download the measuring guide.

2. Then print it out, fill it in and either call us on 352-942-0224 with the measurements or email us at info@stonevos.com or cheryl@stonevos.com and we'll get back to you with a quote.  Please include your name, number, zip code, year/make/model of your RV.

Patio awning, Double stitched Solarfix thread, replacement awning, Weatherwrap, 10 year warranty

A&E Dometic Awnings with no metal cover (in inches):

1. Measure the length of the current awning fabric, left to right, and then measure the length of the roller tube in between the endcaps.

2.  Measure the bead to bead depth or extension from the coach wall to the 1st rail on the roller tube.

3. Find out if the awning wraps around the roller tube 1/3 of the way.

4.  Measure the drop or depth of the valance flap.


 Call us on 352-942-0224 or email us at info@stonevos.com or cheryl@stonevos.com and we'll send you a printable measuring guide.


Girard & Brustor

How to Measure Your Assemblies.

Girard, replacement slide topper, Double-stitched Solarfix thread, CoachGuard, 10 year warranty

Slide toppers (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension of the slideout from the coach wall to the exterior slide wall.

Window replacement awning, Double stitched Solarfix thread, CoachGuard, 10 year warranty

Window Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension of the awning from the lead rail back to the roller tube at the coach wall.

Patio replacement awning, Double stitched Solarfix thread, CoachGuard, 10 year warranty

Door Awning (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension of the awning from the lead rail back to the roller tube at the coach wall.  Estimate how much of a wrap is left on the roller tube.

Patio replacement awning, Double stitched Solarfix thread, CoachGuard, 10 year warranty

Patio Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension of the awning from the lead rail back to the roller tube at the coach wall.  Estimate how much of a wrap is on the roller tube.


LCI Lippert Solera

How to measure your LCI Solera assemblies.

Slide topper replacement awning, Double stitched Solarfix thread, Migliore, 10 year warranty

LCI Solera Slide Toppers (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension of the slideout from the coach wall to the exterior slide wall.

Window replacement awning, Double stitched Solarfix thread, CoachGuard, 10 year warranty

LCI Solera Manual Window Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric and measure the length of the metal cover if you have one.

2.  Measure the depth or extension  of the awning fully deployed from bead to bead.

3.   Measure the drop or depth of the decorative valance flap.

Patio replacement awning, Double stitched Solarfix thread, CoachGuard, 10 year warranty

LCI Solera Patio Awning (in inches):

1. Measure the length of the current awning fabric, left to right, and then measure the length of the roller tube in between the endcaps.

2.  Measure the bead to bead depth or extension from the coach wall to the 1st rail on the roller tube.

3. Find out if the awning wraps around the roller tube 1/3 of the way.

4.  Measure the drop or depth of the decorative valance flap.


Zip Dee

How to measure your Zip Dee assemblies.

Patio replacement awning, Zip Dee, Double-stitched Solarfix thread, CoachGuard, 10 year warranty

Zip Dee Patio Awning (in inches):

1.  Measure the length, left to right, of the current awning fabric.

2.  Measure the depth or extension from the metal cover to the stitchline above the roller tube.

3. Measure the drop or depth of the decorative valance flap.

4.  Measure the length, left to right, of the metal cover.

5. Measure the length & depth of the soft connect or "flex-key".

6. Measure the strap, see PDF below.

Topper replacement awning, Zip Dee, Double-stitched Solarfix thread, CoachGuard, 10 year warranty

Zip Dee Slide Topper / Window Awnings (in inches):

1.  Measure the length, left to right, of the current awning fabric and measure the length of the metal cover if you have one.

2.  Measure the depth or extension from the metal cover to the stitchline above the roller tube.

3. Measure the drop or depth of the decorative valance flap.

4.  Measure the length, left to right, of the metal cover.

5. Measure the length & depth of the soft connect or "flex-key".

6. Measure the strap, see PDF below.

Window replacement awning, Zip Dee, Double-stitched Solarfix thread, CoachGuard, 10 year warranty

Zip Dee Window Awnings (in inches):

1. Measure the length of the current awning fabric, left to right, and then measure the length of the roller tube in between the endcaps.

2.  Measure the depth or extension from the metal cover to the stitchline above the roller tube.

3. Measure the drop or depth of the decorative valance flap.

4.  Measure the length, left to right, of the metal cover.

5. Measure the length and depth  of the soft connect or "flex-key".

6. Measure the strap, see PDF below.

Please don't hesitate to contact us should you have any questions on measuring.

Downloads

CAREFREE OF COLORADO Omega I Measuring Directions 07032024 (pdf)

Download

CAREFREE OF COLORADO Omega II Measuring Directions (pdf)

Download

GIRARD and BRUSTOR awning measuring sheet (pdf)

Download

Dometic A_E 8500 -9100 Power awning WeatherPro measuring instructions (pdf)

Download

Patio Awning Measuring Guide - with or without a metal cover, not WeatherPro slatted cover (pdf)

Download

Zip Dee Awnings How to Measure (jpg)

Download

Zip Dee How to Measure Awning Strap (jpg)

Download

Zip Dee How to Measure Patio Strap (jpg)

Download

PDF Viewer

Download PDF

PDF Viewer

Download PDF
